Dimensions
| Overall Length | 419.7 in (10660 mm) |
| Wheelbase | 218.5 in (5550 mm) |
| Overall Width | 118 in (3000 mm) |
| Overall Height | 106 in (2700 mm) |
| Ground Clearance | 17.8 in (452 mm) |
| Dump Height | 234.1 in (5946 mm) |
| Dump Ground Clearance | 24.4 in (620 mm) |
Weights
| Operating Weight (Empty) | 85554 lb (38800 kg) |
| Operating Weight (Loaded) | 181030 lb (82100 kg) |
| Front Axle Load Distribution | 46% |
| Rear Axle Load Distribution | 54% |
Dump System
| Rated Payload Capacity | 97000 lb (44000 kg) |
| Body Capacity – Heaped | 33 yd3 (25.5 m3) |
Engine Details
| Number of Cylinders | 8 |
| Engine Make | Caterpillar |
| Engine Model | CAT 3408E HEUI |
| Displacement | 1099 cu in (18.0 L) |
| Bore | 5.4 in (137.2 mm) |
| Stroke | 6.0 in (152.4 mm) |
| Gross Power | 490 hp (365 kw) |
| Power Measured @ | 2000 rpm |
| Peak Torque | 1612 lb ft (2186 Nm) |
| Torque Rise | 26 % |
| Fuel System | The hydraulic electronic unit injector fuel system |
| Aspiration | Turbocharged |
Operational Specs
| Max Operaing Weight | 181030 lb (82100 kg) |
| Payload Capacity | 97000 lb (44000 kg) |
| Frame Oscillating | ±12° |
| Articulation Angle | ±42.5° |
| Cab | ROPS + FOPS |
Transmission
| Number of Gears | 8F / 2R |
| Max Forward Speed | 29.9 mph (48.1 km/h) |
| Max Reverse Speed | 6.6 mph (10.6 km/h) |
| Tire Size | 29.5×29.2 Radials |
| Turning Radius (outside) | 363.4 in (9228 mm) |
| Turning Radius (inside) | 208.5 (5296 mm) |
Service Refill Capacities
| Fuel Tank Capacity | 158.6 gal (600 L) |
| Engine Oil Capacity | 12 gal (45.5 L) |
| Cooling System Capacity | 38.3 gal (145 L) |
| Transmission Oil Capacity | 22.5 gal (85 L) |
| Front Differential Fluid Capacity | 25 gal (95 L) |
| Rear Differential Fluid Capacity | 25 gal (95 L) |
| Hydraulic System Capacity (steering) | 31.7 gal (120 L) |
| Steering Hydraulic Tank Capacity | 22.2 gal (84 L) |
