Mast
| Mast Tip Forward | 5 degrees |
| Mast Tip Rear | 6 degrees |
| Load Center | 24.02 in (610 mm) |
| Load Capacity | 10000 lb (4536 kg) |
| Lift Speed | 112 ft/min (34.14 m/min) |
| Lower Speed | 108 ft/min (32.92 m/min) |
Dimensions
| Length To Fork Face | 9.06 ft in (2759 mm) |
| Overall Width | 3.84 ft in (1170 mm) |
| Overall Height – Mast Lowered | 7.01 ft in (2134 mm) |
| Wheelbase | 5.88 ft in (1790 mm) |
| Ground Clearance | 6.15 in (156 mm) |
| Height To Top Of Overhead Guard | 7.14 ft in (2175 mm) |
| Gradeability | 32 % |
| Turning Radius | 8.03 ft in (2447 mm) |
Engine Details
| Number Of Cylinders | 4 |
| Engine Make | Kubota |
| Engine Model | Kubota WG3800-L LPG |
| Displacement | 230 cu in (3.8 L) |
| Power | 91 hp (69 kw) |
| Power Measured @ | 2400 rpm |
| Torque | 221 lb ft (300 Nm) |
| Torque Measured @ | 1000 rpm |
| Emission Standards | EPA Tier 2 / CARB Tier 3 |
Operational Specs
| Operating Weight | 15329 lb (6953 kg) |
| Front Axle Load | 6338 lb (2875 kg) |
| Rear Axle Load | 8991 lb (4078 kg) |
| Drawbar Pull | 3803 lb (1725 kg) |
| Operating Voltage | 12 V |
| Battery | 12 V, CCA 475 |
| Working Light Package 1 | 2 front and 1 rear work lights (halogen or high intensity LED) |
| Working Light Package 2 | 2 front, 1 rear work light and 2 brake/tail/back-up lights (halogen or high intensity LED) |
Transmission
| Type | 1 speed powershift transmission. Optional: DuraMatch 2 speed electronically controlled transmission |
| Max Travel Speed | 10.5 mph (16.9 km/h) |
| Max Travel Speed (optional) | 13.5 mph (21.7 km/h) |
| Number Of Front Wheels | 2x |
| Number Of Rear Wheels | 2 |
| Tire Type | Cushion |
| Front Tire Size | 22 x 12 x 16 |
| Rear Tire Size | 18 x 8 x 12.2 |
| Service Brake | Heavy duty premium wet disc brakes. Hydraulic single pedal inch brake |
| Parking Brake | Hand/Mechanical |
Hydraulic System
| Type | 3-function hydraulic control valve |
| Steering | Hydrostatic power steering |
| Hydraulic Control Levers | Cowl-mounted hydraulic control levers |
| Hydraulic System Relief Valve Pressure | 2250 psi (15500 kPa) |
Service Refill Capacities
| Fuel Tank | Swing out LPG tank bracket. Optional: Dual LPG tank bracket |
| Engine Oil Capacity | 3.22 gal (12.2 L) |
| Cooling System Capacity | 2.38 gal (9.0 L) |
| Hydraulic Tank Capacity | 20.5 gal (77.7 L) |
