Bucket
| Bucket Capacity, Heaped |
2.35 yd3 (1.8 m3) |
| Bucket Width |
98.4 in (2500 mm) |
| Reach at Max Lift and Dump |
39.4 in (1000 mm) |
| Dump Clearance At Max Raise |
112.6 in (2860 mm) |
| Hinge Pin – Max Height |
152 in (3860 mm) |
| Bucket Dump Angle, Fully Raised |
45° |
| Rollback, Boom Fully Raised |
56° |
| Cutting Depth |
1.2 in (30 mm) |
| Breakout Force |
19176 lbf (85.3 kN) |
Data for GP Bucket (2.35 yd3 / 1.8 m3 capacity) with Volvo TP-linkage
Dimensions
| Length w/ Bucket on Ground |
271.3 in (6890 mm) |
| Length w/o Bucket |
224.4 in (5700 mm) |
| Width Over Tires |
94 in (2390 mm) |
| Height to Top of Cab |
125.2 in (3180 mm) |
| Wheelbase |
112 in (2840 mm) |
| Ground Clearance |
17.7 in (450 mm) |
Data for GP Bucket (2.35 yd3 / 1.8 m3 capacity) with Volvo TP-linkage
Engine Details
| Number Of Cylinders |
6 |
| Engine Make |
Volvo |
| Engine Model |
Volvo TD 63 KDE |
| Displacement |
334 cu in (5.5 L) |
| Net Power |
122 hp (90 kw) |
| Gross Power |
130 hp (96 kw) |
| Power Measured @ |
2100 rpm |
| Max Torque |
453.6 lb ft (615 Nm) |
| Torque Measured @ |
1100 rpm |
| Aspiration |
Turbocharged |
Operational Specs
| Min Operating Weight |
23665 lb (10730 kg) |
| Max Operating Weight |
25287 lb (11470 kg) |
| Static Tipping Load 2.35 yd3 (1.8 m3) GP Bucket |
17020 lb (7720 kg) |
| Operating Voltage |
24 V |
| Alternator |
60 amps |
| Battery |
2x 12 V, 105 Ah, CCA 690 |
| Rear Axle Oscillation |
26° |
| Tire Size |
20.5 R25*L2 |
| Turning Radius |
222 in (5635 mm) |
Transmission
| Transmission Type |
Volvo APS II (Automatic Power Shift With Mode Selector) |
| Number Of Forward Gears |
4 |
| Number Of Reverse Gears |
3 |
| Max Forward Speed |
27.3 mph (44.0 km/h) |
| Max Reverse Speed |
16.2 mph (26.0 km/h) |
Hydraulic System
| Type |
Load-sensing hydraulics |
| Pump Type |
Double axial piston pump |
| Relief Valve Setting |
3771 psi (26000 kPa) |
| Pump Flow Capacity |
42.3 gal/min (160 L/min) |
| Raise Time |
5.1 sec |
| Dump Time |
1.3 sec |
| Lower Time, Empty |
3.0 sec |
Service Refill Capacities
| Fuel Tank Capacity |
50.2 gal (190 L) |
| Engine Oil Capacity |
4.3 gal (16 L) |
| Cooling System Capacity |
10.6 gal (40 L) |
| Hydraulic System Capacity |
17.2 gal (65 L) |
| Transmission Fluid Capacity |
4.5 gal (17 L) |
| Front Axle/Diff Fluid Capacity |
6.4 gal (24 L) |
| Rear Axle/Diff Fluid Capacity |
6.4 gal (24 L) |
