Volvo FH16 6×4 T-ride Truck

Contents

Dimensions
Wheelbase Option (Cab-to-Chassis Truck) 1
Wheelbase Option (Cab-to-Chassis Truck) 2
Wheelbase Option (Cab-to-Chassis Truck) 3

Dimensions

Height To Top Of Cab	10.91 ft in (3325 mm)
Weight Class	8
Tire Size	front: 315/80R22.5, rear: 315/80R22.5
Number Of Rear Axles	2
Overall Width	8.19 ft in (2495 mm)

Wheelbase Option (Cab-to-Chassis Truck) 1

Overall Length	22.1 ft in (6735 mm)
Wheelbase	125.99 in (3200 mm)
Length From Center of Rear Axle(s) to End of Frame	31.7 in (805 mm)
Total Chassis Weight	20789.59 lb (9430 kg)
Turning Radius	25.1 ft in (7650 mm)
Total GVW	57320.19 lb (26000 kg)

Wheelbase Option (Cab-to-Chassis Truck) 2

Overall Length	22.76 ft in (6935 mm)
Wheelbase	133.86 in (3400 mm)
Length From Center of Rear Axle(s) to End of Frame	31.7 in (805 mm)
Total Chassis Weight	20833.69 lb (9450 kg)
Total GVW	57320.19 lb (26000 kg)
Turning Radius	25.6 ft in (7800 mm)

Wheelbase Option (Cab-to-Chassis Truck) 3

Overall Length	23.41 ft in (7135 mm)
Wheelbase	141.74 in (3600 mm)
Length From Center of Rear Axle(s) to End of Frame	31.7 in (805 mm)
Total Chassis Weight	20899.83 lb (9480 kg)
Total GVW	57320.19 lb (26000 kg)
Turning Radius	28.88 ft in (8800 mm)
