Dimensions
| Length w/ Bucket | 129.5 in (3289 mm) |
| Length w/o Bucket | 102.3 in (2598 mm) |
| Width Over Tires | 65 in (1651 mm) |
| Tread Width | 54.5 in (1384 mm) |
| Wheelbase | 40 in (1016 mm) |
| Height to Top of Cab | 78 in (1981 mm) |
| Ground Clearance | 8 in (203 mm) |
| Angle of Departure | 28.6° |
| Turning Radius From Center – Machine Rear | 60.5 in (1537 mm) |
| Turning Radius From Center – With Bucket | 77.0 in (1956 mm) |
Loader Performance
| Standard Bucket Width | 66 in (1676 mm) |
| Rated Operating Capacity | 1500 lb (680 kg) |
| Tipping Load (w/o counterweight) | 3000 lb (1369 kg) |
| Max Operating Height | 148.3 in (3767 mm) |
| Height to Hinge Pin | 113.8 in (2891 mm) |
| Dump Height | 89.8 in (2281 mm) |
| Reach at Max Lift and Dump | 24.0 in (610 mm) |
| Dump Angle | 36° |
| Max Rollback Angle | 29° |
Tires
| Front Tire Size (Standard) | 10.00×16.5 8PR |
| Rear Tire Size (Standard) | 10.00×16.5 8PR |
| Tire Size, non-pneumatic (Optional) | 7.00 x 15 solid; 7.50 x 15 segmented; 10.00 x 16.5 segmented |
| Tire Size, super flotation (Optional) | 31.00 x 15.5 x 15 8PR |
Engine Details
| Number of Cylinders | 4 |
| Engine Make | Kubota |
| Engine Model | Kubota V2003-TE |
| Displacement | 122 cu in (2 L) |
| Bore | 3.27 in (83 mm) |
| Stroke | 3.64 in (92.4 mm) |
| Gross Power | 60 hp (44.7 kw) |
| Power Measured @ | 2800 rpm |
| Fuel System | Indirect injection |
| Air Cleaner | Dual element air cleaner |
| Aspiration | Turbocharged |
Operational Specs
| Operational Weight | 5957 lb (2702 kg) |
| Rated Operating Capacity | 1500 lb (680 kg) |
| Operating Voltage | 12 V |
| Battery | 12 V, CCA 525 (CCA 800) |
| Cab | Tilt forward ROPS/FOPS cab |
| Working Lights | 2 front lights + 1 rear working light |
Transmission
| Type | Hydrostatic transmission |
| Max Travel Speed | 7 mph (11.1 km/h) |
| Parking Brake | Mechanical park lock |
| Control | Dual travel / steering levers |
Hydraulic System
| Type | High Flow auxiliary hydraulics with flat face couplers |
| Pump Flow Capacity | 31 gal/min (117 L/min) |
| Max Working Pressure | 2500 psi (17237 kPa) |
| Hydraulic Tank Heater | Optional |
Service Refiil Capacities
| Fuel Tank Capacity | 17.3 gal (65.5 L) |
| Engine Oil Capacity | 2.4 gal (9 L) |
| Cooling System Capacity | 2.6 gal (10 L) |
| Hydraulic System Capacity | 10 gal (37.8 L) |
