Dimensions
| Length with Bucket On Ground | 254.3 in (6460 mm) |
| Width Over Tires | 86.2 in (2190 mm) |
| Width Over Bucket | 88.6 in (2250 mm) |
| Height To Top Of Cab | 117.3 in (2980 mm) |
| Wheelbase | 104.3 in (2650 mm) |
| Ground Clearance | 17.1 in (435 mm) |
Loader
| Bucket Width | 88.6 in (2250 mm) |
| Breakout Force (GP Bucket) | 16186 lbf (72 kN) |
| Reach At Max Lift And Dump | 38 in (965 mm) |
| Dump Clearance At Max Raise | 112.8 in (2865 mm) |
| Hinge Pin – Max Height | 148.8 in (3780 mm) |
Engine Details
| Number of Cylinders | 4 |
| Engine Make | Volvo |
| Engine Model | Volvo D4H |
| Displacement | 244.1 cu in (4 L) |
| Net Power | 116 hp (85 kw) |
| Gross Power | 118 hp (87 kw) |
| Power Measured @ | 1900 rpm |
| Max Torque | 345 lb ft (468 Nm) |
| Torque Measured @ | 1450 rpm |
| Aspiration | Turbocharged |
| Emission Standards | US EPA Tier 4i / EU Stage III B |
Operational Specs
| Operating Weight (w/ GP Bucket) | 20746 lb (9410 kg) |
| Operating Weight (w/ High-Tip Bucket) | 21804 lb (9890 kg) |
| Static Tipping Weight | 14462 lb (6560 kg) |
| Operating Voltage | 24 V |
| Alternator | 110 amps |
| Battery | 2x 12 V, 100 Ah, CCA 830 |
| Starter | 7.5 hp (5.5 kw) |
| Tire Size | 17.5-25 / MI 17.5R25 XHA / MI 500/70 R24 XMCL / NO 440/80R24 TRI 2 / GY 550/65R25 GP-3D / TR 600/55-26.5 T421 |
Transmission
| Type | Hydrostatic transmission |
| Number of Gears (Low-speed Version, Forward / Reverse) | 2 / 2 |
| Number of Gears (High-speed Version, Forward / Reverse) | 3 / 3 |
| Max Travel Speed (Low-speed Version) | 12.4 mph (20 km/h) |
| Max Travel Speed (High-speed Version) | 24.9 mph (40 km/h) |
| Service Brakes | Reliable wet disc brakes with nitrogen-charged accumulators. Low-speed version: Single circuit on rear axle / High-speed version (S): Dual circuit on front and rear axle |
| Steering | Load sensing hydrostatic articulated steering |
Hydraulic System
| Pump Type | One load-sensing axial piston pump with variable displacement |
| Pump Flow Capacity | 34.9 gal/min (132 L/min) |
| Max Working Pressure | 3771 psi (26000 kPa) |
| Pilot Working Pressure | 363 psi (2500 kPa) |
| Raise Time | 6.4 sec |
| Dump Time | 1.6 sec |
| Lower Time | 3.9 sec |
| Total Cycle Time | 11.9 sec |
| Steering Pump Flow | 18.5 gal/min (70 L/min) |
| Steering Working Pressure | 2538 psi (17500 kPa) |
Service Refill Capacities
| Fuel Tank Capacity | 39.7 gal (150 L) |
| Engine Oil Capacity | 3.7 gal (14 L) |
| Cooling System Capacity | 5.3 gal (20 L) |
| Hydraulic System Capacity | 25.1 gal (95 L) |
| Transmission Oil Capacity | 0.6 gal (2.2 L) |
| Front Axle/Diff Fluid Capacity | 4.5 gal (17 L) |
| Rear Axle/Diff Fluid Capacity | 4.9 gal (18.3 L) |
