Dimensions
| New Holland T4030 | Standard | Deluxe |
|---|---|---|
| Overall Length (2WD/4WD) | 135.2 in (3433 mm) | 137.5 in (3490 mm) |
| Wheelbase (2WD) | 83.3 in (2110 mm) | 85.6 in (2170 mm) |
| Wheelbase (4WD) | 80.2 in (2030 mm) | 82.6 in (2090 mm) |
| Wheelbase (SuperSteer) | 94.8 in (2400 mm) | 94.8 in (2400 mm) |
| Height (Folded ROPS) | 77.8 in (1976 mm) | 77.8 in (1976 mm) |
| Height to Top of Cab | 91.4 in (2322 mm) | 91.4 in (2322 mm) |
| Front Tread | 48.7 to 76.6 in (1236 to 1945 mm) | 48.7 to 76.6 in (1236 to 1945 mm) |
| Rear Tread | 48.5 to 76.7 in (1232 to 1949 mm) | 48.5 to 76.7 in (1232 to 1949 mm) |
| Ground Clearance | 19.3 in (490 mm) | 19.3 in (490 mm) |
Weight
| Operating Weight (2WD ROPS) | 5776 lb (2619 kg) |
| Operating Weight (4WD ROPS) | 6327 lb (2869 kg) |
| Operating Weight (2WD Cab) | 6217 lb (2820 kg) |
| Operating Weight (4WD Cab) | 6768 lb (3069 kg) |
| Max Front Axle Load (2WD) | 4630 lb (2100 kg) |
| Max Front Axle Load (4WD) | 5511 lb (2499 kg) |
| Max Rear Axle Load | 8157 lb (3700 kg) |
Engine Details
| Number Of Cylinders | 4 |
| Engine Make | FPT Industrial |
| Engine Model | FPT F5C |
| Displacement | 195.3 cu in (3.2 L) |
| Bore | 3.9 in (99 mm) |
| Stroke | 4.1 in (104 mm) |
| Gross Power | 76 hp (56.7 kw) |
| PTO Power | 62 hp (46.3 kw) |
| Power Measured @ | 2300 rpm |
| Aspiration | Turbocharged air to air intercooled |
| Emission Standards | US EPA Tier III |
PTO (Power Take-Off)
| Rear PTO Type | Independent |
| Rear PTO Speed | 540 rpm |
| PTO / Engine RPM | 540@2196 |
| PTO Clutch | 280mm mechanical dry disc |
Operational Specs
| Noise Level | 85.2 dB(A) |
| Operating Voltage | 12 V |
| Alternator | 85 amps |
| Battery | 12 V, CCA 730 |
| Front Tire Size (ag) | 11.2R24 |
| Rear Tire Size (ag) | 16.9R30 |
| Front Tire Size (lawn/turf) | 13.6-16.1; 12LL-16 |
| Rear Tire Size (lawn/turf) | 16.9-24; 22.5L-16.1 |
| Front Tire Size (industrial) | 12.5/80-18 |
| Rear Tire Size (industrial) | 16.9-24 |
Transmission
| Type (Standard) | 12-speed mechanical shuttle Synchro Command transmission |
| Type (Optional) | 16-speed mechanical shuttle Synchro Command transmission |
| Type (Optional) | 16-speed power shuttle shuttle Synchro Command transmission |
| Number Of Reverse Gears | 12F/12R or 16F/16R |
| Max Travel Speed | 24.38 mph (39.23 km/h) |
Hydraulic System
| Type | Open center |
| Standard Pump Flow Capacity | 12.6 gal/min (47.6 L/min) |
| Hight Flow Pump Capacity | 15.0 gal/min (56.7 L/min) |
| Steering Pump Flow Capacity | 7.4 gal/min (28.0 L/min) |
| Steering Pump Flow Capacity (with power shuttle) | 9.4 gal/min (35.6 L/min) |
| Relief Valve Setting | 2880 psi (19900 kPa) |
| Number Of Remote Control Valves | 1 to 5 |
| 3 Point Hitch Type | Cat II/I |
| 3 Point Hitch Lift Capacity @ 24 Inches | 3968 lb (1800 kg) |
Service Refill Capacities
| Fuel Tank Capacity | 21.6 gal (82 L) |
| Fuel Tank Capacity (Deluxe) | 19.8 gal (75 L) |
| Engine Oil Capacity (w/ Filter) | 2.5 gal (9.5 L) |
| Cooling System Capacity, ROPS/Cab | 2.6 gal (10 L) / 3.2 gal (12 L) |
| Cooling System Capacity (Deluxe), ROPS/Cab | 3.7 gal (14 L) / 4.2 gal (16 L) |
| Transmission / Hydraulic Oil Capacity | 11.6 gal (44 L) |
| Front Differential Fluid Capacity | 1.2 gal (4.5 L) |
