Dimensions
| Overall Length | 179.5 in (4560 mm) |
| Wheelbase | 106.7 in (2710 mm) |
| Height to Exhaust | 110.2 in (2800 mm) |
| Height to Top of Canopy | 103.9 in (2640 mm) |
Engine Details
| Number of Cylinders | 6 |
| Engine Make | Perkins |
| Engine Model | Perkins 1006.6T |
| Displacement | 366.2 cu in (6 L) |
| Gross Power | 130 hp (97 kw) |
| PTO Power | 110.3 hp (82.3 kw) |
| Power Measured @ | 2200 rpm |
| Max Torque | 376.2 lb ft (510 Nm) |
| Torque Measured @ | 1400 rpm |
| Aspiration | Turbocharged |
PTO (Power Take-Off)
| Rear PTO Type | Independent |
| Rear PTO Speed | 540 / 1000 rpm |
| PTO Clutch | 1 3/8 in (35 mm) 6-spline shaft |
Operational Specs
| Operating Weight (2WD) | 9083 lb (4120 kg) |
| Operating Voltage | 12 V |
| Battery | 12 V |
| Front Tire Size (2WD) | 9.00-16 |
| Rear Tire Size (2WD) | 18.4-34 |
Transmission
| Type | Synchromesh Transmission |
| Number Of Forward Gears | 12 |
| Number Of Reverse Gears | 4 |
| Max Travel Speed | 19 mph (30 km/h) |
Hydraulic System
| Pump Flow | 4.5 gal/min (17 L/min) |
| Relief Valve Setting | 3046 psi (21000 kPa) |
| Auxiliary Pump Flow | 13.2 gal/min (50 L/min) |
| Auxiliary Relief Valve Setting | 2466 psi (17000 kPa) |
| 3 Point Hitch Type | Cat II |
| 3 Point Hitch Lift Capacity @ 24 Inches | 7054.8 lb (3200 kg) |
Service Refill Capacities
| Fuel Tank Capacity | 55.5 gal (210 L) |
| Engine Oil Capacity | 3.6 gal (13.5 L) |
| Cooling System Capacity | 7.9 gal (30 L) |
