Dimensions
| Overall Length |
211.8 in (5380 mm) |
| Height to Top of Cab |
117.3 in (2980 mm) |
| Minimum Width (w/o straight axle shaft) |
86.2 in (2190 mm) |
| Wheelbase |
111.4 in (2830 mm) |
| Front Track Adjustments |
66.1-85.4 in (1680-2170 mm) |
| Rear Track Adjustments |
64.6-91.7 in (1640-2330 mm) |
Tires
| Front Tire Size (Standard) |
16.9R28 |
| Rear Tire Size (Standard) |
20.8R38 |
| Front Tire Size (Optional) |
480/70R28; 540/65R28 |
| Rear Tire Size (Optional) |
580/70R38; 650/65R38 |
| Turning Circle (w/o brakes) |
448.8 in (11400 mm) |
Engine Details
| Number of Cylinders |
6 |
| Engine Make |
Perkins |
| Engine Model |
Perkins 1006.60TWG |
| Displacement |
366.2 cu in (6 L) |
| Bore |
3.9 in (100 mm) |
| Stroke |
5.0 in (127 mm) |
| Power |
166 hp (124 kw) |
| Power Measured @ |
2200 rpm |
| Peak Torque |
491 lb ft (666 Nm) |
| Torque Measured @ |
1400 rpm |
| Fuel System |
Direct injection |
| Air Cleaner |
Dual dry, with exhaust aspiration |
| Aspiration |
Turbocharged with intercooler |
Operational Specs
| Shipping Weight (Dynashift) |
14429 lb (6545 kg) |
| Max Operating Weight (Dynashift) |
17758 lb (8055 kg) |
| Shipping Weight (Powershift) |
15609 lb (7080 kg) |
| Max Operating Weight (Powershift) |
18067 lb (8195 kg) |
| Operating Voltage |
12 V |
| Alternator |
120 amps |
| Battery |
12 V |
| Noise Level (Inside cab) |
72 dB(A) |
Transmission
| Transmission Type |
32F / 32R Dynashift (Optional – 18F / 8R Powershift) |
| Number of Gears (Dynashift) |
32F / 32R |
| Number of Gears (Powershift) |
18F / 8R |
| Min Forward Speed (Dynashift) |
1.6 mph (2.6 km/h) |
| Max Forward Speed (Dynashift) |
25 mph (40.2 km/h) |
| Min Forward Speed (Powershift) |
1.4 mph (2.2 km/h) |
| Max Forward Speed (Powershift) |
24.4 mph (39.3 km/h) |
| Steering |
Hydrostatic power steering. Tilt/telescopic steering column |
| Steering Angle |
±55° |
| Service Brakes |
Oil-cooled, with hydraulic actuation |
| Parking Brake |
Independant, multi-plate disc on transmission, hand lever operated |
| Trailer Brakes |
Hydraulic, pedal operated |
Note: Reverse speeds are matched to related forward speed. Top gear is locked out for markets restricted to 18.6 mph (30 km/h) max speed.
Hydraulic System
| Type |
Closed centre load sensing sytem |
| Pump Flow Capacity |
29.1 gal/min (110 L/min) |
| Pump Flow Capacity, w/ Powershift (Optional) |
39.6 gal/min (150 L/min) |
| Max Pressure |
2900 psi (20000 kPa) |
| Number of Remote Control Valves |
3 |
3-Point Hitch
| 3 Point Hitch Type |
Category III |
| 3 Point Hitch Lift Capacity @ ends |
19180 lb (8700 kg) |
| Draft Control |
Electronic. Intermix, height/depth, rate of drop, Quick Soil Engagement and Active Transport Control |
| Front 3 Point Hitch Type (Optional) |
Category III |
| Front 3 Point Hitch Lift Capacity @ ends (Optional) |
7716 lb (3500 kg) |
PTO (Power Take-Off)
| Rear PTO Type |
Independent, operated by switch, actuated by hydraulic clutch, with electronic control |
| PTO Speed |
540 / 1000 |
| Shaft Change |
Shiftable / flanged |
| PTO Shaft Diameter |
1 3/8 in (35 mm), 6 or 21 splines |
| PTO / Engine RPM |
540 @ 2090 / 1000 @ 2090 |
| Front PTO Type (Optional) |
Independent, operated by switch, actuated by hydraulic clutch |
| Front PTO Speed (Optional) |
1000 |
| Front PTO / Engine RPM |
1000 @ 2040 |
Service Refill Capacities
| Fuel Tank Capacity |
108.3 gal (410 L) |
| Engine Oil Capacity |
4.1 gal (15.6 L) |
| Cooling System Capacity |
7.5 gal (28.5 L) |
| Hydraulic / Transmission Oil Capacity (HD Sealed Final Drive, Dynashift) |
31.4 gal (119 L) |
| Hydraulic / Transmission Oil Capacity (Heavy Duty Final Drive, Dynashift) |
33.3 gal (126 L) |
| Hydraulic / Transmission Oil Capacity (HD Sealed Final Drive, Powershift) |
38.8 gal (147 L) |
| Hydraulic / Transmission Oil Capacity (Heavy Duty Final Drive, Powershift) |
40.7 gal (154 L) |
| Front Differential Fluid Capacity (AG 200CDH1) |
2.7 gal (10.2 L) |
| Front Differential Fluid Capacity (AG 280CDHP) |
4.2 gal (16 L) |
| Front Differential Fluid Capacity (Carraro 20.29) |
1.6 gal (6 L) |
| Front Differential Fluid Capacity (Carraro 20.43) |
1.6 gal (6 L) |
| Front Differential Fluid Capacity (Carraro 20.48) |
2.6 gal (10 L) |
