Dimensions
| Overall Length | 167 in (4243 mm) |
| Overall Width | 75.7 in (1923 mm) |
| Overall Height | 102.1 in (2594 mm) |
| Wheelbase | 88 in (2235 mm) |
| Front Tire Size | 440 / 65R24 |
| Rear Tire Size | 540 / 65R34 |
| Minimum Turning Radius | 170.5 in (4330 mm) |
Weights
| Operating Weight | 8157 lb (3700 kg) |
| Maximum Operating Weight | 13228 lb (6000 kg) |
Engine Details
| Number Of Cylinders | 4 |
| Engine Make | Case IH FPT |
| Engine Model | Case IH FPT 3.2L |
| Maximum Engine Power | 99 hp (73 kw) |
| Power Measured @ | 2300 rpm |
| Peak Torque | 300 lb ft (407 Nm) |
| Torque Measured @ | 1500 rpm |
| Torque Rise | 34% |
| Displacement | 195.3 cu in (3.2 L) |
| Bore | 3.9 in (99 mm) |
| Stroke | 4.1 in (104 mm) |
| Block Design | Parent bore |
| Fuel Injection | Direct |
| Fan Drive Method | Fixed ratio |
| Fuel System | Rotary-Distributor Type |
| Aspiration | Turbocharged and Intercooled |
| Emission Standards | Tier 3 + Stage III B |
Operating Specs
| Operating Voltage | 12 V |
| Alternator | 120 amps |
| Fuel Tank Capacity | 30.4 gal (115 L) |
Transmission
| Transmission Type | 24 x 24 Powershift with powershuttle / 40 x 40 Powershift with powershuttle and creeper |
| Max Travel Speed | 24.8 mph (40 km/h) |
| Number Of Forward Gears | 24 / 40 |
| Number Of Reverse Gears | 24 / 40 |
| Service Brake | Wet disc brakes |
| Axle Output End | Flange |
| Final Drive | Inboard Planetary |
| Steering Type | Electro-hydraulic |
| Final Drive | Inboard Planetary |
Power Take-off (PTO)
| PTO Horsepower | 85 hp (63.4 kw) |
| PTO Type | Fully independent |
| Engagement Type | Electro-hydraulic |
| PTO Speeds | 540/540E |
Hydraulic System
| Hydraulic System Type | Open Center |
| Pump Type | Gear |
| Total Pump Flow | 26.4 gal/min (100 L/min) |
| Implement Pump Flow | 16.8 gal/min (63.5 L/min) |
| Steering Pump Flow | 9.6 gal/min (36.5 L/min) |
| Number Of Remote Control Valves | 3 rear / 2 mid |
3-Point Hitch
| Drawbar Description | Swinging |
| Category | Category 2 or 1 |
| Front Hitch Lift Capacity | 3682 lb (1670 kg) |
| Rear Hitch Lift Capacity | 8157 lb (3700 kg) |
| Draft Sensing | Top link sensing |
