Dimensions
| Type | 2WD | MFWD |
|---|---|---|
| Wheelbase | 94 in (2380 mm) | 92 in (2330 mm) |
| Height to Top of ROPS | 101.1 in (2560 mm) | 101.1 in (2560 mm) |
| Height to Top of Cab | 103.1 in (2610 mm) | 103.1 in (2610 mm) |
| Front Tire Size | 13.5R24 | 13.5R24 |
| Rear Tire Size | 18.4R34 | 18.4R34 |
Weight
| Type | 2WD | MFWD |
|---|---|---|
| Operating Weight (ROPS) | 6107 lb (2770 kg) | 6659 lb (3020 kg) |
| Operating Weight (Cab) | 6768 lb (3069 kg) | 7320 lb (3320 kg) |
Engine Details
| Number Of Cylinders | 4 |
| Engine Make | Case IH FPT |
| Engine Model | Case IH FPT 4.5 L |
| Gross Power | 90 hp (67.2 kw) |
| PTO Power | 80 hp (59.7 kw) |
| Power Measured @ | 2500 rpm |
| Displacement | 274.7 cu in (4.5 L) |
| Bore | 4.1 in (104 mm) |
| Stroke | 5.2 in (132 mm) |
| Aspiration | Turbocharged |
Operational Specs
| Operating Voltage | 12 V |
| Alternator | 85 amps |
| Battery | 12 V, CCA 850 |
| Fuel Tank Capacity | 23.8 gal (90 L) |
| Rear PTO Type | Independent with mechanical dry clutch |
| Rear PTO Speeds | 540, optional: 540/1000 |
| Rear Hitch Type | 2 |
| 3 Point Hitch Lift Capacity @ 24 Inches | 5025 lb (2279 kg) |
| Control | Position control and mechanical lower-link draft sensing |
Transmission
| Transmission Type | 12-speed mechanical shuttle | 20-speed mechanical shuttle with creeper |
|---|---|---|
| Number Of Forward Gears | 12 | 20 |
| Number Of Reverse Gears | 12 | 20 |
| Max Travel Speed | 24.8 mph (40 km/h) | 24.8 mph (40 km/h) |
Hydraulic System
| Hydraulics Type | Open center |
| Relief Valve Setting | 2755 psi (18995 kPa) |
| Total Pump Flow | 21.7 gal/min (82.1 L/min) |
| Pump Flow | 13.6 gal/min (51.5 L/min) |
| Steering Flow | 8.1 gal/min (30.7 L/min) |
| Rear Valves | 1 to 3 |
