Mustang 2066 Skid Steer Loader

Contents
  1. Dimensions
  2. Engine Details
  3. Operational Specs
  4. Loader
  5. Hydraulic

Dimensions

Length With Bucket 10.76 ft in (3277 mm)
Width Over Tires 5.34 ft in (1626 mm)
Ground Clearance 7.9 in (201 mm)
Height To Top Of Cab 6.76 ft in (2060 mm)
Wheelbase 3.59 ft in (1092 mm)
Length W/O Bucket 7.75 ft in (2362 mm)
Clearance At Max Lift And Dump 3.38 ft in (1029 mm)
Reach At Max Lift And Dump 95 in (2413 mm)
Turning Radius From Center – Machine Rear 62.6 in (1590 mm)

Engine Details

Number Of Cylinders 4
Engine Make Yanmar
Engine Model 4TNV98 / TIER III
Net Power 68 hp (51 kw)
Power Measured @ 2500 rpm
Displacement 202 cu in (3.3 L)

Operational Specs

Operational Weight 7460 lb (3384 kg)
Fuel Tank Capacity 19 gal (72 L)
Hydraulic System Fluid Capacity 16 gal (60.5 L)
Max Speed 11.4 mph (18.3 km/h)
Operating Voltage 12 V
Alternator Supplied Amperage 950 amps

Loader

Breakout Force 6692 lb (29.7 kg)
Operating Load Rating 2300 lb (1043 kg)
Tipping Angle 4000 degrees
Bucket Capacity 0.7 yd3 (0.5 m3)

Hydraulic

Pump Flow Capacity 21.5 gal/min (81 L/min)
Relief Valve Pressure 3000 psi (20684.3 kPa)
