Komatsu PC40MR-2 Mini Excavator

Contents
  1. Dimensions
  2. Undercarriage
  3. Engine Details
  4. Operational Specs
  5. Swing Mechanism
  6. Buckets

Dimensions

Width To Outside Of Tracks 5.08 ft in (1560 mm)
Length Of Track On Ground 6.57 ft in (2000 mm)
Ground Clearance 1.19 ft in (360 mm)
Height To Top Of Cab 8.58 ft in (2625 mm)
Tail Swing Radius 3.5 ft in (1060 mm)
Removal Counterweight Clearance 2 ft in (608 mm)

Undercarriage

Max Travel Speed 2.9 mph (4.6 km/h)
Number Of Carrier Rollers Per Side 1
Number Of Track Rollers Per Side 4

Engine Details

Engine Make Komatsu
Engine Model 4D88E-5
Gross Power 39.4 hp (29.4 kw)
Power Measured @ 2.2 rpm (2.189 rpm)
Displacement 134 cu in (2.2 L)

Operational Specs

Operating Weight 10560 lb (4790 kg)
Fuel Tank Capacity 17.2 gal (65 L)
Cooling System Fluid Capacity 1.9 gal (7.3 L)
Operating Voltage 12 V
Hydraulic System Fluid Capacity 14.5 gal (55 L)
Engine Oil Capacity 2.1 gal (8 L)

Swing Mechanism

Swing Speed 9 rpm

Buckets

Reference Bucket Capacity 0.1 yd3
Minimum Bucket Capacity 0.1 yd3
Maximum Bucket Capacity 0.3 yd3 (0.2 m3)
