Dimensions
| Overall Length | 194 in (4928 mm) |
| Overall Width | 113 in (2870 mm) |
| Height to Top of ROPS | 110 in (2794 mm) |
| Length of Track on Ground | 131.4 in (3338 mm) |
Undercarriage
| Track Gauge | 84 in (2134 mm) |
| Shoe Size (Standard) | 24 in (610 mm) |
| Number of Carrier Rollers Per Side | 2 |
| Number of Track Rollers Per Side | 6 |
| Number of Shoes Per Side | 38 |
Engine Details
| Number of Cylinders | 12 |
| Engine Make | Detroit Diesel |
| Engine Model | Detroit Diesel 12V-71T |
| Displacement | 852 cu in (13.97 L) |
| Bore | 4.25 in (108 mm) |
| Stroke | 5.00 in (127 mm) |
| Gross Power | 374 hp (276 kw) |
| Power Measured @ | 2100 rpm |
| Peak Torque | 1450 lb ft (1966 Nm) |
| Torque Measured @ | 1600 rpm |
| Aspiration | Turbocharged |
| Compression Ratio | 17.0:1 |
| Fuel Consumption, 50% Power | 17.1 gal/h (64.9 L/h) |
| Fuel Consumption, 75% Power | 24.9 gal/h (94.3 L/h) |
| Fuel Consumption, 100% Power | 33.8 gal/h (128.1 L/h) |
Operational Specs
| Operating Weight (20% fuel) | 67360 lb (30554 kg) |
| Operating Voltage | 24 V |
| Alternator | 50 amps |
| Battery | 2x 12 V, 90 Ah |
| Noise level | 103.5 dB(A) |
Transmission
| Model | Allison CRT-7031 |
| Type | 3-Speed Power Shaft Transmission |
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 3 |
| Max Travel Speed | 7.0 mph (11.2 km/h) |
| Service Brakes | Self-adjusting oil cooled, multiple disc, full power modulated foot brake |
| Parking Brake | Automatically applied when engine is stopped |
| Steering | Self adjusting, oil cooled, multiple disc clutches and brakes |
Service Refill Capacities
| Fuel Tank Capacity | 125 gal (473 L) |
| Engine Oil Capacity (with Filter) | 12.5 gal (47.3 L) |
| Cooling System Capacity | 49 gal (185 L) |
