Boom
| Max Height @ Max Raise Angle – No Jib | 140.1 ft in (42.7 m) |
| Max Height @ Max Raise Angle | 189.3 ft in (57.7 m) |
| Max Lift Capacity | 100231 lb (50000 kg) |
| Boom Raising Time | 88 sec |
| Boom Full Extension Time | 180 sec |
| Number Of Sections | 5 |
Dimensions
| Transport Length | 42.98 ft in (13100 mm) |
| Transport Width | 9.03 ft in (2750 mm) |
| Transport Height | 11 ft in (3350 mm) |
| Upper Structure Tail Swing Radius | 11.43 ft in (3482 mm) |
| Ground Clearance | 11.5 in (291 mm) |
| Gradeability | 27 % |
| Approach Angle | 16 degrees |
| Angle Of Departure | 11 degrees |
Engine Details
| Number Of Cylinders | 6 |
| Engine Make | Weichai |
| Engine Model | Weichai WD615.67A |
| Gross Power | 276.3 hp (206 kw) |
| Power Measured @ | 2200 rpm |
| Max Torque | 811.4 lb ft (1100 Nm) |
| Torque Measured @ | 1400 rpm |
| Aspiration | Turbocharged |
Operational Specs
| Operating Weight | 90390 lb (41000 kg) |
| Front Axle Load | 33070 lb (15000 kg) |
| Rear Axle Load | 57320 lb (26000 kg) |
| Max Travel Speed | 50 mph (80 km/h) |
