Rotary Cutter
| Cutting Width | 6.6 ft in (2010 mm) |
| Cutting Depth | 12.6 in (320 mm) |
| Number Of Tools | 178 |
Conveyor System
| Discharge Conveyor Width | 31.5 in (800 mm) |
| Collecting Conveyor Width | 31.5 in (800 mm) |
| Discharge Conveyor Swing (R/L) | 45° |
Dimensions
| Operating Length | 45.38 ft in (13830 mm) |
| Shipping Width | 8.21 ft in (2500 mm) |
| Shipping Height | 10.01 ft in (3050 mm) |
| Shipping Length | 36.88 ft in (11240 mm) |
| Max Operating Height | 14.77 ft in (4500 mm) |
Engine Details
| Number of Cylinders | 8 |
| Engine Make | Mercedes-Benz |
| Engine Model | Mercedes-Benz OM 502 LA |
| Displacement | 970 cu in (15.9 L) |
| Bore | 5.1 in (130 mm) |
| Stroke | 5.9 in (150 mm) |
| Gross Power | 509.6 hp (380 kw) |
| Power Measured @ | 1800 rpm |
| Peak Torque | 1918 lb ft (2600 Nm) |
| Torque Measured @ | 1080 rpm |
| Aspiration | Turbocharged and intercooled |
Operational Specs
| Operating Weight – Full Load | 64375 lb (29200 kg) |
| Shipping Weight – Empty | 60627 lb (27500 kg) |
| Operating Speed | 95.2 ft/min (29 m/min) |
| Travel Speed | 2.8 mph (4.5 km/h) |
Service Refill Capacities
| Fuel Tank Capacity | 211.4 gal (800 L) |
| Engine Oil Capacity | 10 gal (38 L) |
| Cooling System Capacity | 10 gal (38 L) |
| Water Spray System Fluid Capacity | 792.6 gal (3000 L) |
