Massey Ferguson 1529 4WD Tractor

Contents

Dimensions
Operational Specs
Engine Details
Transmission
Hydraulic System
Service Refill Capacities

Dimensions

Overall Length	10.03 in (3055 mm)
Height To Top Of Cab	8.09 ft in (2465 mm)
Wheelbase	5.57 in (1695 mm)
Ground Clearance	10.44 in (265 mm)
Track Width	58.08 in (1475 mm)

Operational Specs

Operating Weight	2579 lb (1170 kg)
Operating Voltage	12 V
Alternator	40 amps
Drive	4WD

Engine Details

Number of Cylinders	3
Engine Make	Iseki
Engine Family	7ICLL1.50C3D
Engine Model	Iseki E3CD
Displacement	91.4 cu in (1.498 L)
Gross Power	28 hp (20.9 kw)
Power Measured @	2500 rpm
Peak Torque	67.3 lb ft (91.3 Nm)
Torque Measured @	1500 rpm
PTO Power	23.2 hp (17.4 kw)
Aspiration	Naturally aspirated

Transmission

Type	8-speed mechanical transmission
Number of Gears	8F / 8R
Max Travel Speed	13.4 mph (21.6 km/h)

Hydraulic System

Pump Flow Capacity	10.8 gal/min (40.9 L/min)
3 Point Hitch Type	Cat I
3 Point Hitch Lift Capacity @ 24″	2425 lb (1100 kg)

Service Refill Capacities

Fuel Tank Capacity	8.5 gal (32 L)
Engine Oil Capacity	0.82 gal (3.1 L)
Cooling System Capacity	1.64 gal (6.2 L)
Front Axle Oil Capacity	1.27 gal (4.8 L)
