Dimensions
| Overall Length | 163.8 in (4161 mm) |
| Overall Width | 82.7 in (2100 mm) |
| Overall Height to Top of Cab | 106 in (2693 mm) |
| Wheelbase | 92.5 in (2350 mm) |
| Centre of Rear Axle to Roof | 74.7 in (1897 mm) |
Weights
| Operating Weight | 9149 lb (4150 kg) |
| Maximum Operating Weight | 16314 lb (7400 kg) |
Engine Details
| Number Of Cylinders | 4 |
| Engine Make | Case IH FPT |
| Engine Model | FPT 3.4 L |
| Rated Engine Power | 114 hp (84 kw) |
| Power Measured @ | 2300 rpm |
| Peak Torque | 340 lb ft (461 Nm) |
| Torque Measured @ | 1500 rpm |
| Torque Rise (OECD) | 32% |
| Displacement | 207.5 cu in (3.4 L) |
| Bore | 3.9 in (99 mm) |
| Stroke | 4.4 in (110 mm) |
| Block Design | Parent bore block |
| Aspiration | Turbocharged and intercooled |
| Fuel System | High Pressure Common Rail |
| Fuel Injection | Direct with Electronic Fuel System Control |
| Fan Drive Type | Belt |
| Emissions Level | Stage IIIB compliant |
Power Take-off (PTO)
| PTO Type | Independent |
| PTO Horsepower | 98 hp (73 kw) |
| PTO Engagement Type | Electro-hydraulic engagement |
| Rear PTO Speed | 540 / 540E / 1000 |
| Front PTO Speed (optional) | 1000 |
Electrical System
| Operating Voltage | 12 V |
| Alternator | 120 amps |
Transmission
| Type | 2-speed Powershift + Powershuttle Transmission. Optional; 12F x 12R Powershuttle / 20F x 20R Powershuttle w/ Creeper |
| Number Of Gears | 24F / 24R |
| Maximum Speed Forward | 24.9 mph (40 km/h) |
| Steering | Front Steer |
| Drive | 4WD |
Hydraulic System
| Hydraulic System Type | Open Center with CCLS remotes |
| Main Pump Type | Dual gear pump |
| Implement Pump Flow | 17.2 gal/min (65 L/min) / Optional: 22.2 gal/min (84 L/min) |
| Control Type | EHC (Electronic Hitch Control) |
| Number Of Remote Control Valves | 2 with flow control / Optional: max 3 with 1 diverter |
3-Point Hitch
| Category | Category 2 |
| Lift Capacity @ Link End | 11905 lb (5400 kg) |
| Lift Capacity @ 24” | 10516 lb (4770 kg) |
| Draft Sensing | Electronic Draft Control |
| Drawbar Description | Swinging, Category 2 |
Axles, Tires & Brakes
| Rear Axle | Flange |
| Final Drive | Inboard planetary |
| Service Brake | Wet disc |
| Front Tire Size | 480/65 R24, 14.9R24 |
| Rear Tire Size | 540/65 R38, 18.4R34 |
Service Refill Capacities
| Fuel Tank Capacity | 37 gal (140 L) |
| Engine OIl Capacity | 2.1 gal (8 L) |
| Cooling System Capacity | 4.6 gal (17.3 L) |
