Dimensions
| Shipping Length | 187.8 in (4770 mm) |
| Overall Width | 68.5 in (1740 mm) |
| Track Gauge | 56.7 in (1440 mm) |
| Height to Top of Cab | 97.2 in (2470 mm) |
| Ground Clearance | 12.6 in (320 mm) |
| Track Shoe Size | 12 in (300 mm) |
Working Range
| Max Digging Depth | 135 in (3440 mm) |
| Max Reach at Ground Level | 207.5 in (5270 mm) |
| Max Dump Height | 134.2 in (3410 mm) |
| Boom Swing – Right | 65° |
| Boom Swing – Left | 43° |
| Bucket Digging Force | 7216 lb (32.1 kN) |
| Arm Digging Force | 4586 lb (20.4 kN) |
Dozer Blade
| Dozer Blade Type | Backfill Dozer Blade |
| Blade Width | 68.5 in (1740 mm) |
| Blade Stroke | 16.7 in (425 mm) |
| Blade Raise | 14.6 in (370 mm) |
Swing Mechanism
| Swing Speed | 9.5 rpm |
Engine Details
| Number off Cylinders | 3 |
| Engine Make | Yanmar |
| Engine Model | Yanmar 3TNV88F-ESBV |
| Displacement | 100.2 cu in (1.6 L) |
| Bore | 3.46 in (88 mm) |
| Stroke | 3.54 in (90 mm) |
| Gross Power | 24.4 hp (18.2 kw) |
| Power Measured @ | 2200 rpm |
| Aspiration | Naturally aspirated |
| Emission Standards | US EPA Tier 4 Final + EU Stage V |
Operational Specs
| Operating Weight (Cab + Steel Tracks) | 8434 lb (3830 kg) |
| Operating Weight (Cab + Rubber Tracks) | 8214 lb (3720 kg) |
| Operating Weight (Canopy + Steel Tracks) | 8125 lb (3680 kg) |
| Operating Weight (Canopy + Rubber Tracks) | 7905 lb (3580 kg) |
| Operating Voltage | 12 V |
| Alternator | 35 amps |
| Battery | 12 V, 80 Ah |
| Ground Pressure (Canopy + Rubber Tracks) | 4.80 psi (33.1 kPa) |
| Ground Pressure (Cab + Rubber Tracks) | 4.97 psi (34.3 kPa) |
Drivetrain
| Type | Hydrostatic Transmission |
| Min Travel Speed | 1.68 mph (2.7 km/h) |
| Max Travel Speed | 2.8 mph (4.5 km/h) |
Hydraulic System
| Hydraulic System Type | Closed-center |
| Hydraulic Pump | 2x Variable Displacement Pumps + 2x Gear Pumps |
| Hydraulic Flow Capacity (Variable Displacement Pump) | 2x 9.8 gal/min (37.0 L/min) |
| Hydraulic Flow Capacity (Gear Pump) 1 | 6.9 gal/min (26.2 L/min) |
| Hydraulic Flow Capacity (Gear Pump) 2 | 2.9 gal/min (10.8 L/min) |
| Hydraulic System Relief Valve Pressure | 3205 psi (22100 kPa) |
Service Refill Capacities
| Fuel Tank Capacity | 10.8 gal (41 L) |
| Engine Oil Capacity | 1.9 gal (7.2 L) |
| Cooling System Capacity | 1.3 gal (5.0 L) |
| Hydraulic Tank Capacity | 10.6 gal (40 L) |
