Dimensions
| Length To Fork Face | 112.6 in (2861 mm) |
| Wheelbase | 70.5 in (1790 mm) |
| Overall Width | 42 in (1067 mm) |
| Lift Height, Top of Fork (TOF) | 110 in (2800 mm) |
| Height to Top of Overhead Guard | 86 in (2175 mm) |
| Ground Clearance | 6.15 in (156 mm) |
| Turning Radius | 100 in (2534 mm) |
| Gradeability | 24 / 28 % |
Operating Specs
| Operating Weight | 16690 lb (7570 kg) |
| Front Axle Load | 5994 lb (2719 kg) |
| Rear Axle Load | 10695 lb (4851 kg) |
| Drawbar Pull | 7784 lb (3531 kg) |
| Operating Voltage | 12 V |
| Battery | 12 V, CCA 475 |
| Working Light | 2 front + 1 rear work lights (halogen or LED) |
Mast
| Mast Tip Forward | 5 degrees |
| Mast Tip Rear | 6 degrees |
| Load Center | 24 in (610 mm) |
| Load Capacity | 12000 lb (5443 kg) |
| Lift Speed | 110 ft/min (33.53 m/min) |
| Lower Speed | 100 ft/min (30.48 m/min) |
Engine Details
| Number Of Cylinders | 4 |
| Engine Make | Kubota |
| Engine Model | Kubota WG3800-L LPG |
| Displacement | 230 cu in (3.8 L) |
| Power | 91 hp (69 kw) |
| Power Measured @ | 2400 rpm |
| Torque | 221 lb ft (300 Nm) |
| Torque Measured @ | 1000 rpm |
| Aspiration | Naturally aspirated |
| Emission Standards | EPA Tier 2 / CARB Tier 3 + EU Stage V |
Transmission
| Transmission Type | 1-speed powershift transmission |
| Optional Transmission | DuraMatch 2 speed electronically controlled transmission |
| Max Travel Speed | 10.4 mph (16.8 km/h) |
| Max Travel Speed (optional) | 13.4 mph (21.6 km/h) |
| Number Of Front Wheels | 2x |
| Number Of Rear Wheels | 2 |
| Tire Type | Cushion |
| Front Tire Size | 22 x 12 x 16 |
| Rear Tire Size | 18 x 8 x 12.2 |
| Service Brake | Heavy duty premium wet disc brakes. Hydraulic single pedal inch brake |
| Parking Brake | Hand/Mechanical |
Hydraulic System
| Hydraulic System Type | 3-function hydraulic control valve |
| Steering Type | Hydrostatic power steering |
| Hydraulic Control Levers | Cowl-mounted hydraulic control levers |
| Relief Valve Pressure | 2250 psi (15500 kPa) |
Service Refill Capacities
| Engine Oil Capacity | 3.22 gal (12.2 L) |
| Cooling System Capacity | 2.38 gal (9.0 L) |
| Hydraulic Fluid Reservoir | 20.5 gal (77.7 L) |
| Fuel Tank | Swing out LPG tank bracket / Dual LPG tank bracket (optional) |
