Dimensions
| Track Gauge | 9.09 ft in (2770 mm) |
| Height – Top Of Cab | 15.25 ft in (4646 mm) |
| Overall Length | 34.54 ft in (10525 mm) |
| Track Length On Ground | 14.85 ft in (4524 mm) |
| Blade Length | 254.6 in (6465 mm) |
| Blade Height | 126.8 in (3220 mm) |
| Blade Cut Depth | 33.9 in (860 mm) |
| Ground Clearance | 25.79 in (655 mm) |
Undercarriage
| Grouser Height | 4.1 in (105 mm) |
| Shoe Size | 31.9 in (810 mm) |
| Ground Contact Area | 11360 in2 (73290 cm2) |
| Ground Pressure (Tractor) | 16.2 psi (112 kPa) |
| Number of Shoes (each side) | 41 |
| Number of Track Rollers | 8 |
| Number of Carrier Rollers | 2 |
| Suspension | Oscillating equalizer bar and pivot shaft |
| Track Roller Frame | Cylindrical, high-tensile-strength steel construction |
Engine Details
| Number Of Cylinders | 12 |
| Engine Make | Komatsu |
| Engine Model | Komatsu SAA12V140 |
| Displacement | 1860 cu in (30.5 L) |
| Power, Gross (SAE J1995) | 900 hp (671 kw) |
| Power, Net (SAE J1349) | 860 hp (641 kw) |
| Power, Net (ISO 9249) | 860 hp (641 kw) |
| Fan Drive Method | Hydraulic |
Driveline
| Type | Komatsu TORQFLOW transmission |
| Gearshift | Gearshift lock lever and neutral safety switch prevent accidental starts |
| Maximum Forward Speeds | 7 mph (11.2 km/h) |
| Maximum Reverse Speeds | 8.7 mph (14 km/h) |
| Number Of Speeds (Forward / Reverse) | 3 / 3 |
Operational Specs
| Blade Capacity | 58.9 yd3 (45 m3) |
| Blade Type | Super Dozer blade |
| Blade Length | 254.6 in (6465 mm) |
| Blade Height | 126.8 in (3220 mm) |
| Blade Cut Depth | 33.9 in (860 mm) |
Weights
| Max Operating Weight | 249560 lb (113200 kg) |
| Base Tractor Weight | 186310 lb (84510 kg) |
| Ripper Weight | 16230 lb (7360 kg) |
| Counterweight | 14110 lb (6400 kg) |
| Super Dozer Blade Weight | 47070 lb (21350 kg) |
Hydraulic System
| Hydraulic System Type | Closed-center load sensing system (CLSS) |
| Pump Flow | 143 gal (542 L/min) |
| Relief Valve Setting | 3980 psi (27500 kPa) |
Service Refill Capacities
| Fuel Tank Capacity | 441 gal (1670 L) |
| Cooling System Capacity | 55.5 gal (210 L) |
| Engine Oil Capacity | 32 gal (121 L) |
| Transmission Oil Capacity | 55.5 gal (210 L) |
| Super Dozer Hydraulic Oil (additional capacity) | 48 gal (180 L) |
| Final Drives Capacity (each side) | 19.8 gal (75 L) |
