Loader
| Bucket Capacity – Heaped | 2.4 yd3 (1.8 m3) |
| Static Tipping Load | 23086 lb (10470 kg) |
| Bucket Breakout Force | 27675 lb (12550 kN) |
| Clearance At Full Height And Dump | 9.25 ft in (2820 mm) |
| Reach At Dump Height | 3.5 ft in (1072 mm) |
Dimensions
| Length With Bucket On Ground | 20.08 ft in (6132 mm) |
| Length To Front Of Track | 14.25 ft in (4339 mm) |
| Width To Outside Of Tracks | 7.33 ft in (2235 mm) |
| Height To Top Of Cab | 10.25 ft in (3129 mm) |
| Ground Clearance | 1.3 ft in (395 mm) |
Undercarriage
| Track Gauge | 66 in (1680 mm) |
| Length Of Track On Ground | 8.17 ft in (2478 mm) |
| Track Shoe Width | 22 in (560 mm) |
| Ground Contact Area | 4302 in2 (2.78 m2) |
| Ground Pressure | 7.9 psi (54 kPa) |
| Number Of Track Rollers Per Side | 6 |
| Number Of Shoes Per Side | 42 |
Engine Details
| Number Of Cylinders | 4 |
| Engine Make | Liebherr |
| Engine Model | Liebherr D 924 T-E a1 |
| Displacement | 409 cu in (6.7 L) |
| Net Power | 130 hp (97 kw) |
| Power Measured @ | 2000 rpm |
| Max Torque | 432 lb ft (585 Nm) |
| Torque Measured @ | 1400 rpm |
| Aspiration | Turbocharged |
Operational Specs
| Operating Weight | 33950 lb (15400 kg) |
| Operating Voltage | 24 V |
| Alternator | 55 amps |
Power Train
| Transmission Type | Dual-path, electronic-controlled, closed loop hydrostatic drive |
| Max Travel Speed (Low Range) | 3.1 mph (5 km/h) |
| Max Travel Speed (High Range) | 6.8 mph (11 km/h) |
| Replenishment Pump Type | Gear |
| Replenishment Pump Flow | 22 gal/min (83 L/min) |
| Travel Drive Pump Type | Variable-flow, swash plate type |
| Travel Drive Pump Flow | 41 gal/min (154 L/min) |
| Travel Drive Motor | Bent-axis type, variable-flow motor |
Hydraulic System
| Pump Type | Axial-piston, swash plate type |
| Pump Flow Capacity | 41 gal/min (156 L/min) |
| Relief Valve Pressure | 3770 psi (26000 kPa) |
| Stand-By Pressure | 290-305 psi (2000-2100 kPa) |
| Raise (From Ground to Maximum) Time | 6.4 sec |
| Lower (Maximum to Ground) Time | 2.1 sec |
| Tilt In (Ground Level to Maximum) Time | 1.2 sec |
| Tilt In (Maximum to Maximum) Time | 2.7 sec |
| Tilt Out (Upside: Maximum to Maximum) Time | 1.1 sec |
Service Refill Capacities
| Fuel Tank Capacity | 69 gal (260 L) |
| Cooling System Capacity w/ Recovery Tank | 11 gal (42 L) |
| Cooling System Capacity (Series II) | 18 gal (68 L) |
| Engine Oil Capacity w/ Filter | 4.8 gal (18 L) |
| Engine Oil Capacity w/ Filter (Series II) | 5.3 gal (20 L) |
| Final Drive Fluid Capacity (Each) | 8.9 gal (8.5 L) |
| Hydraulic System Capacity w/ Tank & Filter | 34 gal (130 L) |
| Splitter Drive Capacity | 0.7 gal (2.5 L) |
