Loader
| Bucket Capacity – Struck | 0.9 yd3 (0.7 m3) |
| Bucket Capacity – Heaped | 1.1 yd3 (0.8 m3) |
| Static Tipping Load | 8896 lb (4035 kg) |
| Bucket Breakout Force | 10700 lb (47.6 kN) |
| Clearance At Full Height And Dump | 97 in (2465 mm) |
| Reach At Dump Height | 30.9 in (785 mm) |
Dimensions
| Length | 153.1 in (3890 mm) |
| Length Of Track On Ground | 71.8 in (1824 mm) |
| Width To Outside Of Tracks | 70.1 in (1780 mm) |
| Height To Top Of Cab | 107 in (2718 mm) |
| Ground Clearance | 12.4 in (315 mm) |
Undercarriage
| Track Gauge | 56 in (1420 mm) |
| Track Shoe Width | 12 in (305 mm) |
| Ground Contact Area | 1736 in2 (1.13 m2) |
| Number Of Track Rollers Per Side | 5 |
Engine Details
| Number of Cylinders | 4 |
| Engine Make | Caterpillar |
| Engine Model | Cat 3204 |
| Displacement | 317.4 cu in (5.2 L) |
| Bore | 4.5 in (114 mm) |
| Stroke | 5.0 in (127 mm) |
| Net Power | 62 hp (46 kw) |
| Power Measured @ | 2400 rpm |
Operational Specs
| Operating Weight | 15212 lb (6900 kg) |
| Static Tipping Load | 8896 lb (4035 kg) |
| Operating Voltage | 12 V |
| Max Speed | 6.9 mph (11.1 km/h) |
Hydraulic
| Raise Time | 6.1 sec |
| Dump Time | 1.3 sec |
| Lower Time | 3.5 sec |
Service Refill Capacities
| Fuel Tank Capacity | 30.3 gal (114.5 L) |
| Engine Oil Capacity | 3.2 gal (12 L) |
| Cooling System Capacity | 5.3 gal (20 L) |
| Hydraulic System Capacity | 13 gal (50 L) |
