Dimensions
| Combine Class Size | Class VI |
| Length (feeder to rear trim panel) | 302.7 in (7689 mm) |
| Wheelbase (2WD Axle / PGA) | 150.2 in (3815 mm) |
| Transport Height (To Top of Cab) | 153.8 in (3906 mm) |
| Width (Overall Single Tires 120″ Tread) | 150.9 in (3833 mm) |
Headers
| Grain Header Cutting Widths | 193 in (4.9 m) / 205 in (5.2 m) / 240 in (6.1 m) / 264 in (6.7 m) / 299 in (7.6 m) |
| Knife to Auger Distance – 2030 Grain Header | 21.6 in (550 mm) adjustable from cab |
| Knife to Auger Distance – 3050 Grain Header | 22.4 – 44.9 in (570 – 1140 mm) adjustable from cab |
| Corn Header Model 4400 Rigid and Foldable | 6 & 8 row chopping corn heads |
Feeding
| Feeder Width | 45.6 in (1156 mm) |
| Feeder Speed Variable | 2-speed standard |
| Feeder Reverser Control | Electro-Hydraulic |
| Feeder Tilt Adjustment | Fore-aft standard, Lateral standard |
| Stone Or Rock Protection | Stone trap |
Threshing
| Threshing Area | 156.5 in2 (0.1 m2) |
| Concave Adjustment | Electric |
| Threshing System Type- Rotary Or Conventional Cylinder | Longitudinal rotor |
| Number Of Rotors Or Cylinders | 1 Rotor |
| Rotor Or Cylinder Description | Staggered Rasp Bars |
| Rotor Or Cylinder Diameter | 30 in (762 mm) |
| Rotor Or Cylinder Length | 110 in (2794 mm) |
| Rotor Or Cylinder Speed Range | 250 to 1150 rpm (3 ranges) |
Cleaning System
| Total Sieve Area (Fixed Cleaning System) | 8556 in2 (5.52 m2) |
| Total Sieve Area (CrossFlow Cleaning System) | 8370 in2 (5.40 m2) |
| Cleaning System Width | 58 in (1473 mm) |
| Leveling System Available | Fixed or CrossFlow |
| Cleaning Fan Speed Range | 450 to 1300 rpm |
| Cleaning Fan Diameter | 11.4 in (290 mm) |
Grain Handling
| Reach From Machine Center – Standard Auger | 25.8 ft (7.86 m) |
| Reach From Machine Center – Optional Auger | 21.6 ft (6.6 m) |
| Grain Tank Capacity | 300 bu (10572 L) |
| Unloading Speed | 3.2 bu/sec (113 L/sec) |
Engine Details
| Number Of Cylinders | 6 |
| Engine Make | Case IH FPT |
| Engine Model | FPT 8.7 L Cursor 9 |
| Displacement | 531 cu in (8.7 L) |
| Bore | 4.6 in (117 mm) |
| Stroke | 5.3 in (135 mm) |
| Max Horsepower | 411 hp (306 kw) |
| Rated Horsepower | 348 hp (260 kw) |
| Power Measured @ | 2000 rpm |
| Power Boost | 63 hp (47 kw) |
| Aspiration | Turbocharged, intercooled |
| Emission Standards | US EPA Tier 2 |
Operating Specs
| Weight, Basic Machine | 32187 lb (14600 kg) |
| Operating Weight, 2WD Single Tires | 34130 lb (15481 kg) |
| Operating Weight, 2WD Dual Tires | 37130 lb (16842 kg) |
| AFS Precision Farming Ready | Optional |
| Guidance Ready | Optional |
| Operating Voltage | 12 V |
| Alternator | 185 amps |
| Transmission Type | Hydrostatic drive, 3 speed ranges |
| Steering Axle | Heavy duty adjustable steering axle |
| Front Tire Size | 800/65R32 LI172 R1W 900/60R32 LI176 R1W |
| Rear Tire Size | 480/70R30 LI152 R1W 600/65R28 LI154A8 R1W |
Service Refill Capacities
| Fuel Tank Capacity | 250 gal (945 L) |
| DEF Tank Capacity | 43 gal (166 L) |
| Engine Oil Capacity | 6.6 gal (25 L) |
| Cooling System Capacity | 7.1 gal (27 L) |
