Dimensions
| Overall Length | 33.53 ft in (10220 mm) |
| Overall Width | 8.85 ft in (2700 mm) |
| Overall Height | 10.68 ft in (3257 mm) |
| Wheelbase | 13.69 ft in (4175 mm) |
| Dump Height | 21.51 ft in (6559 mm) |
| Dump Ground Clearance | 2.23 ft in (677 mm) |
| Ground Clearance | 2.16 ft in (659 mm) |
Dump
| Rated Payload | 52911 lb (24000 kg) |
| Capacity – Struck | 15.3 yd3 (11.7 m3) |
| Capacity – Heaped | 19.61 yd3 (15.0 m3) |
| Dump Angle | 72° |
| Lower Time | 9 sec |
| Raise Time | 12 sec |
Weights
| Front Axle – Empty | 26808 lb (12160 kg) |
| Rear Axle – Empty | 20723 lb (9400 kg) |
| Total Empty | 47531 lb (21560 kg) |
| Front Axle – Loaded | 31173 lb (14140 kg) |
| Rear Axle – Loaded | 69269 lb (31420 kg) |
| Total Loaded | 100442 lb (45560 kg) |
Engine Details
| Number Of Cylinders | 6 |
| Engine Make | Volvo |
| Engine Model | Volvo D9B ABE3 |
| Displacement | 574 cu in (9.4 L) |
| Gross Power | 300 hp (224 kw) |
| Net Power | 299 hp (223 kw) |
| Power Measured @ | 2100 rpm |
| Max Torque | 1254 lb ft (1700 Nm) |
| Torque Measured @ | 1200 rpm |
| Aspiration | Turbocharged and Intercooled |
| Emission Standards | US EPA Tier 3, CARB Tier 3, EU Stage III |
Operational Specs
| Load Capacity, Struck (SAE) | 15.3 yd3 (11.7 m3) |
| Load Capacity, Heap (SAE 2:1) | 19.61 yd3 (15.0 m3) |
| Payload | 52911 lb (24000 kg) |
| Net Weight | 47531 lb (21560 kg) |
| Gross Weight | 100442 lb (45560 kg) |
| Operating Voltage | 24 V |
| Alternator | 80 amps |
| Battery | 2x 12V, 170 Ah |
| Starter | 9,5 hp (7.0 kw) |
| Front Tire Size | 23,5R25 |
| Rear Tire Size | 23,5R25 |
Transmission
| Transmission Type | Volvo PowerTronic planetary transmission |
| Number Of Forward Gears | 6 |
| Number Of Reverse Gears | 2 |
| Max Speed | 32.9 mph (53 km/h) |
Hydraulic System
| Pumps | 4x engine-driven variable displacement load-sensing piston pumps driven by the flywheel PTO |
| Steering | One ground-dependent piston pump for secondary steering mounted on the dropbox |
| Filtration | One fibreglass filter with magnetic core |
| Main Pump Flow | 38.6 gal/min (146 L/min) |
| Steering Pump Flow | 32.2 gal/min (122 L/min) |
| Working Pressure | 3626 psi (25000 kPa) |
Service Refill Capacities
| Fuel Tank Capacity | 106 gal (400 L) |
| Cooling System Capacity | 30.4 gal (115 L) |
| Engine Oil Capacity | 10.6 gal (40 L) |
| Transmission Oil Capacity | 11 gal (41 L) |
| Hydraulic System Capacity | 46 gal (175 L) |
| Dropbox Capacity | 2.2 gal (8,5 L) |
| Axles, Front/Rear | 8.7 gal (33 L) |
| First Bogie Axle Capacity | 9.0 gal (34 L) |
