Dump
| Rated Payload | 55116 lb (25000 kg) |
| Capacity – Heaped SAE 1:1 | 21.2 yd3 (16.2 m3) |
| Capacity – Heaped SAE 2:1 | 17.4 yd3 (13.3 m3) |
| Capacity – Struck | 13.1 yd3 (10.0 m3) |
| Dump Angle | 62° |
| Up Time | 8.2 sec |
| Down Time | 7.1 sec |
Dimensions
| Overall Length | 333.6 in (8473 mm) |
| Overall Width | 125.9 in (3199 mm) |
| Overall Height | 139.5 in (3543 mm) |
Operating Weight
| Dezzi AD25B 6×6 | Tare | Gross | Payload |
|---|---|---|---|
| Front Axle | 20900 lb (9480 kg) | 41844 lb (18980 kg) | 20944 lb (9500 kg) |
| Rear Axle | 16358 lb (7420 kg) | 50530 lb (22920 kg) | 34172 lb (15500 kg) |
| Total Weight | 37258 lb (16900 kg) | 92374 lb (41900 kg) | 55116 lb (25000 kg) |
Engine Details
| Number Of Cylinders | 6 |
| Engine Make | Cummins |
| Engine Model | Cummins QSB6.7 |
| Displacement | 408 cu in (6.7 L) |
| Gross Power | 260 hp (194 kw) |
| Power Measured @ | 2200 rpm |
| Max Torque | 730 lb ft (990 Nm) |
| Torque Measured @ | 1500 rpm |
| Aspiration | Turbocharged |
| Emission Standards | US EPA Tier 3 + EU Stage III |
Operational Specs
| Voltage | 24 V |
| Alternator | 70 amps, 24 V |
| Battery | 2x 12 V |
| Tire Size | 26.5 R25 |
| Drive | 4×4 AWD (Optional 4×2) |
| Steering Angle | 36° |
Axle & Brakes
| Dezzi AD25B | 4×4 | 4×2 |
|---|---|---|
| Front Axle | ZF MT-D 3095 axle – with self leveling air-ride suspension | Desmond Axle with self leveling air-ride suspension |
| Rear Axle | ZF MT-D 3135 axle – rigid mounted | ZF MT-D 3135 axle – rigid mounted |
| Service Brake | Front Wheels – Sealed outboard wet disc brakes / Rear Wheels – Dry disc caliper brakes | |
| Parking Brake | Failsafe spring-applied hydraulic release. Heavy duty SAHR park brake | |
Transmission
| Transmission Type | ZF 6WG210 Constant mesh counter shaft with integral drop box |
| Torque Converter | Single phase 3 element, lock-up clutches effective in all gears. Downshift protection |
| Number Of Gears | 6F x 3R |
| Max Travel Speed | 26 mph (42 km/h) |
Hydraulic System
| Hydraulic Pump Type | Variable displacement piston pump |
| Working Pressure – Tipping | 2466 psi (17000 kPa) |
| Working Pressure – Steering | 1987 psi (13700 kPa) |
| Hydraulic Filter | Full flow filtration |
Service Refill Capacities
| Dezzi AD25B | 4×4 | 4×2 |
|---|---|---|
| Fuel Tank Capacity | 66 gal (250 L) | 66 gal (250 L) |
| Engine Oil Capacity | 5.5 gal (21 L) | 5.5 gal (21 L) |
| Cooling System Capacity | 13.2 gal (50 L) | 13.2 gal (50 L) |
| Hydraulic System Capacity | 42.3 gal (160 L) | 42.3 gal (160 L) |
| Transmission Oil Capacity | 4.8 gal (18 L) | 4.8 gal (18 L) |
| Rear Axle Differential | 10.6 gal (40 L) | – |
| Front Axle Differential | – | 9.5 gal (36 L) |
| Front Planetary Hubs (Per Side) | – | 2.1 gal (8 L) |
