Massey Ferguson 5455 Tier III 4WD Tractor

Contents

Dimensions
Engine Details
Operational Specs
Transmission
Hydraulic System

Dimensions

Overall Length	13.82 in (4210 mm)
Width Outside Frame	8.37 ft in (2550 mm)
Height To Top Of Cab	9.03 ft in (2752 mm)
Wheelbase	97 in (2464 mm)
Track Width	80.75 in (2051 mm)

Engine Details

Number Of Cylinders	4
Engine Make	Perkins
Engine Model	1104
PTO Power	85 hp (63.4 kw)
Power Measured @	2200 rpm
Displacement	268.6 cu in (4.4 L)
Aspiration	Turbo/Air to Air

Operational Specs

Fuel Tank Capacity	38.4 gal (145 L)
3 Point Hitch Type	Cat II
3 Point Hitch Lift Capacity @ 24 Inches	7817.6 lb (3546 kg)

Transmission

Transmission Type	Power shuttle
Number Of Forward Gears	16
Number Of Reverse Gears	16

Hydraulic System

Pump Flow Capacity

15.1 gal/min (57 L/min)
