Dimensions
| Length | 237 in (6020 mm) |
| Length (w/ hitch) | 269 in (6833 mm) |
| Wheelbase | 116 in (2946 mm) |
| Width (30″ tracks) | 136 in (3454 mm) |
| Width (36″ tracks) | 142 in (3607 mm) |
| Height to Top of Cab | 134 in (3404 mm) |
| Height to Top of Exhaust | 155 in (3937 mm) |
| Ground Clearance | 16 in (406 mm) |
| Ground Clearance (drawbar) | 19 in (483 mm) |
Engine Details
| Number Of Cylinders | 6 |
| Engine Make | John Deere |
| Engine Model | PowerTech Plus 13.5 L |
| Displacement | 823.9 cu in (13.5 L) |
| Bore | 5.2. in (132 mm) |
| Stroke | 6.5 in (165 mm) |
| Gross Power | 530 hp (395.3 kw) |
| Power Measured @ | 2100 rpm |
| Torque Rise | 38 % |
| Air Cleaner | Dual paper elements |
| Aspiration | Turbocharged, air-to-air aftercooling |
Operational Specs
| Operating Weight | 43920 lb (19922 kg) |
| Max Operating Weight | 53000 lb (24040 kg) |
| Operating Voltage | 12 V |
| Alternator | 200 amps |
| Battery | 3x 12 V, CCA 925 |
| Cab | Standard cab with air conditioning |
Transmission
| Transmission Type | 18-speed automatic powershift |
| Number of Forward Gears | 18 |
| Number of Reverse Gears | 6 |
| Max Travel Speed | 21.8 mph (35.1 km/h) |
| Final Drive | Differential steer |
Hydraulic System
| Type | Closed-center pressure flow compensated (PFC) |
| Pump Flow Capacity | 48 gal/min (181.7 L/min) |
| Relief Valve Pressure | 2900 psi (20000 kPa) |
| Number of Remote Control Valves | 4 |
| SCV Flow Capacity | 30 gal/min (113.6 L/min) |
| Control | Position and draft control |
| 3 Point Hitch Type | Category 4/4N |
| 3-Point Hitch Lift Capacity @ 24″ | 15300 lb (6940 kg) |
Service Refill Capacities
| Fuel Tank Capacity | 330 gal (1249 L) |
| Engine Oil Capacity (w/ filter) | 14.8 gal (56 L) |
| Cooling System Capacity (w/ overflow tank) | 14 gal (53 L) |
| Hydraulic System Capacity (w/ hitch) | 27.5 gal (104 L) |
| Hydraulic / Transmission Oil Capacity | 60 gal (227 L) |
| Hydraulic / Transmission Oil Capacity (w/ PTO) | 61 gal (230 L) |
