Dimensions
| Wheelbase | 90.6 in (2300 mm) |
| Overall Width | 67.8 in (1723 mm) |
| Overall Height w/ ROPS | 102 in (2590 mm) |
| Overall Height w/ Folded ROPS | 80 in (2030 mm) |
| Ground Clearance (2WD, Front) | 18.9 in (480 mm) |
| Ground Clearance (MFWD, Front) | 17.1 in (435 mm) |
| Front Tread Range (2WD) | 58.6 – 81.5 in (1488 – 2070 mm) |
| Front Tread Range (MFWD) | 57.1 – 78.9 in (1451 – 2005 mm) |
| Rear Tread Range (2WD, MFWD) | 65.4 – 75.1 in (1660 – 1907 mm) |
| Turning Radius w/o Brakes | 13.1 ft (4.0 m) |
| Shipping Weight (2WD) | 7937 lb (3600 kg) |
| Shipping Weight (MFWD) | 8598 lb (3900 kg) |
Tires
| Front Tire Size, 2WD | 11L-15 8PR F2 Firestone |
| Front Tire Size, MFWD | 320/85R24 (12.4R24) R1W Radial Firestone |
| Rear Tire Size, 2WD | 460/85R30 (18.4R30) R1W Firestone |
| Rear Tire Size, MFWD | 460/85R30 (18.4R30) R1W Firestone |
Engine Details
| Number Of Cylinders | 4 |
| Engine Make | John Deere PowerTech PWL |
| Engine Family | John Deere FJDXL04.5211 |
| Engine Model | John Deere 4045H |
| Displacement | 274.7 cu in (4.5 L) |
| Bore | 4.19 in (106 mm) |
| Stroke | 5.00 in (127 mm) |
| Engine Power | 113.9 hp (85 kW) |
| Power Measured @ | 2200 rpm |
| Rated PTO Power | 100 hp (74.5 kW) |
| PTO Power Measured @ | 2100 rpm |
| Peak Torque | 354 lb ft (480 Nm) |
| Torque Measured @ | 1600 rpm |
| PTO Torque Rise | 30% |
| Aspiration | Turbocharged Air-to-Air Aftercooled |
| Emission Standards | US EPA Tier 4 Final + EU Stage IIIB |
Operational Specs
| Max Operating Weight (2WD) | 13228 lb (6000 kg) |
| Max Operating Weight (MFWD) | 16535 lb (7500 kg) |
| Operating Voltage | 12 V |
| Alternator (OOS / Cab) | 70 amps / 90 amps |
| Battery | 12 V, 90 Ah, CCA 950 |
| Steering | Hydrostatic power steering |
| Service Brakes | Hydraulic Wet Disc Brakes |
Transmission
| Transmission Type (Standard) | 16F/16R PowrReverser |
| Transmission Type (Option 1) | 12F/4R SyncShuttle Plus |
| Transmission Type (Option 2) | 32F/16R PowrReverser Plus |
| Clutch Type | Wet clutch |
| Reverser | Left hand, mechanical |
| Max Travel Speed | 25 mph (40 km/h) |
Rear Axle
| Final Drive Type | Inboard Planetary |
| Differential Controls | Electrohydraulic |
| Axle Type | Flanged |
| Rear Axle Differential Lock | Electrohydraulic |
| Brakes, Type And Control | Hydraulic wet disc |
Hydraulic System
| Hydraulic Type | Open Center |
| Hydraulic Pump Flow | Standard: 94 L/min 24.7 gpm |
| Available Flow At a Single Rear SCV | 70 L/min 18.4 gpm |
| Joystick SCV Control | Standard |
Rear Hitch
| Hitch Draft Control Load Sense Type | Mechanical or electrohydraulic |
| Hitch Category | Category 2; convertible to 1 |
| Remote Control Valves Available | 2 / 3 Optional |
| 3 Point Hitch Lift Capacity @ 24″ | 6750 lb (3062 kg) |
| 3 Point Hitch Lift Capacity @ Ends | 9790 lb (4441 kg) |
| Sensing Type | Lower link |
PTO (Power Take-Off)
| Rear PTO Type | Independent 540/540 Economy / Optional: 540/540E/1000 |
| Engine / PTO Speed | 540 at 2100 rpm 540E at 1645 rpm |
| PTO Actuation | Electrohydraulic |
Service Refill Capacities
| Fuel Tank Capacity (OOS) | 37.2 gal (141 L) |
| Fuel Tank Capacity (Cab) | 45 gal (170 L) |
| DEF Tank Capacity (OOS) | 3.5 gal (13.2 L) |
| DEF Tank Capacity (Cab) | 5 gal (18.9 L) |
| Engine Oil Capacity | 3.4 gal (13 L) |
| Cooling System Capacity (OOS) | 5.2 gal (19.5 L) |
| Cooling System Capacity (Cab) | 5.8 gal (22 L) |
| Transmission / Hydraulic Oil Capacity | 10.4 gal (39.5 L) |
| MFWD Axle Housing | 1.3 gal (5 L) |
| MFWD Hubs (Each) | 0.2 gal (0.8 L) |
