Dimensions
| Overall Length | 279.3 in (7094 mm) |
| Width Outside Frame | 144.1 in (3660 mm) |
| Height To Top Of Cab | 147.2 in (3739 mm) |
| Wheelbase | 145.7 in (3700 mm) |
| Ground Clearance | 22.52 in (572 mm) |
Hydraulic System
| Type | Full load sensing system serving the prioritized steering, scraper and brake functions |
| Pump Type | Variable displacement, loadsensing piston |
| Pump Flow Capacity | 79.3 gal/min (300 L/min) |
| Relief Valve Pressure | 2900 psi (20000 kPa) |
Operational Specs
| Fuel Tank Capacity | 128 gal (485 L) |
| Operating Weight | 46244 lb (20976 kg) |
| Tire Size | 875/65R29 |
| Alternator | 100 amps, 28 V |
| Operating Voltage | 24 V |
| Battery | 2x 12 V, 105 Ah |
| Drive | 4×4 Articulated Tractor |
| Maximum Articulation Angle | 42° |
| Approach Angle | 31° |
Engine Details
| Number Of Cylinders | 6 |
| Engine Make | Mercedes Benz |
| Engine Model | Mercedes Benz OM501LA |
| Gross Power | 422.5 hp (315 kw) |
| Net Power | 413.1 hp (308 kw) |
| Power Measured @ | 1800 rpm |
| Gross Torque | 1473 lb ft (2000 Nm) |
| Net Torque | 1453 lb ft (1974 Nm) |
| Torque Measured @ | 1080 rpm |
| Displacement | 729.3 cu in (12 L) |
| Aspiration | Turbocharged and intercooled |
Transmission
| Type | Allison HD 4060 constant meshing planetary gears |
| Number Of Forward Gears | 6 |
| Number Of Reverse Gears | 1 |
| Max Speed – Forward | 24.2 mph (39 km/h) |
| Max Speed – Reverse | 3.5 mph (5.6 km/h) |
