Dimensions
| Overall Length | 279.3 in (7094 mm) |
| Overall Width | 134.5 in (3417 mm) |
| Overall Height | 151.1 in (3837 mm) |
| Height to Top of Cab | 147.2 in (3739 mm) |
| Wheelbase | 145.7 in (3700 mm) |
| Ground Clearance | 22.56 in (573 mm) |
| Approach Angle | 31° |
| Maximum Articulation Angle | 42° |
Weight
| Operating Weight (GVM) | 41635 lb (18882 kg) |
| Front Axle | 30036 lb (13622 kg) |
| Rear Axle | 11598 lb (5260 kg) |
Operational Specs
| Fuel Tank Capacity | 128 gal (4855 L) |
| Operating Voltage | 24 V |
| Alternator | 100 amps, 28 V |
| Battery | 2x 12 V, 105 Ah |
| Tire Size | 29.5R25 Radial Earthmover. Optional: 30.5LX32 High flotation agressive tread pattern / 30.5LX32 Agricultural Tyre |
Engine Details
| Number Of Cylinders | 6 |
| Engine Make | Mercedes Benz |
| Engine Model | Mercedes Benz OM501LA |
| Gross Power | 389 hp (290 kw) |
| Net Power | 380 hp (283 kw) |
| Power Measured @ | 1800 rpm |
| Gross Torque | 1362 lb ft (1850 Nm) |
| Net Torque | 1343 lb ft (1824 Nm) |
| Torque Measured @ | 1080 rpm |
| Displacement | 730 cu in (12 L) |
| Bore | 4.1 in (130 mm) |
| Stroke | 5.9 in (150 mm) |
| Aspiration | Turbocharged and intercooled |
| Emission Standards | EPA Tier 3 / EU Stage III |
Transmission
| Transmission Model | Allison HD 4060 transmission, engine mounted box with rear output |
| Gear Layout | Constant meshing planetary gears, clutch operated |
| Clutch Type | Hydraulically operated multi-disc |
| Torque Converter Layout | Hydrodynamic with lock-up in all gears |
| Number Of Forward Gears | 6 |
| Number Of Reverse Gears | 1 |
| Max Forward Speed | 24.2 mph (39.0 km/h) |
| Max Reverse Speed | 3.4 mph (5.5 km/h) |
| Drive | 4×4 Articulated Tractor |
Hydraulic System
| Type | Full load sensing system serving the prioritized steering, scraper and brake functions |
| Pump Type | Variable displacement load sensing piston |
| Pump Flow Capacity | 79.3 gal/min (300 L/min) |
| Relief Valve Pressure | 2900 psi (20000 kPa) |
| Hydraulic Oil Filter | 10 microns |
Braking System
| Service Brake | Dual circuit, full hydraulic actuation ventilated dry disc brakes |
| Maximum Brake Force | 30124 lbf (134 kN) |
| Parking & Emergency Brake | Spring applied, air released driveline-mounted disc |
| Maximum Brake Force | 98920 lbf (440 kN) |
| Auxiliary Brake | Automatic exhaust brake and Engine Valve Brake (EVB) |
