Loader Performance
| Tipping Load | 5400 lb (2449 kg) |
| Rated Operating Capacity | 2700 lb (1225 kg) |
| Breakout Force | 5795 lbf (25.8 kN) |
| Standard Bucket Width | 70 in (1778 mm) |
| Overall Operating Height – Fully Raised | 167.4 in (4252 mm) |
| Height to Hinge Pin – Fully Raised | 130.3 in (3310 mm) |
| Dump Reach at Full Height | 32 in (813 mm) |
| Dump Height | 100 in (2540 mm) |
| Dump Angle | 42° |
| Rollback at Full Height | 94° |
| Rollback at Ground Level | 29° |
Dimensions
| Overall Length w/ Bucket | 148 in (3759 mm) |
| Overall Length w/o Bucket | 116.5 in (2959 mm) |
| Wheelbase | 49.5 in (1257 mm) |
| Height to Top of ROPS | 81 in (2057 mm) |
| Ground Clearance | 8 in (203 mm) |
| Seat to Ground Height | 40 in (1016 mm) |
| Overall Width w/o Bucket | 69.5 in (1765 mm) |
| Overall Width w/ Bucket | 70 in (1778 mm) |
| Clearance Radius – Rear | 65.5 in (1664 mm) |
| Clearance Radius – Front w/o Bucket | 56 in (1422 mm) |
| Clearance Radius – Front w/Bucket | 90 in (2286 mm) |
| Departure Angle | 25° |
Engine Details
| Number of Cylinders | 4 |
| Engine Make | Yanmar |
| Engine Model | Yanmar 4TNV98CT – NMS |
| Displacement | 202.5 cu in (3.319 L) |
| Bore | 3.86 in (98 mm) |
| Stroke | 3.94 in (100 mm) |
| Net Power | 70.7 hp (52.7 kw) |
| Power Measured @ | 2500 rpm |
| Peak Torque | 218.3 lb ft (296 Nm) |
| Torque Measured @ | 1625 rpm |
| Aspiration | Turbocharged |
| Aftertreatment | DPF |
| Emission Standards | US EPA Tier 4 Final |
Operational Specs
| Operational Weight | 8150 lb (3697 kg) |
| Max Lift Height | 130.3 in (3310 mm) |
| Operating Voltage | 12 V |
| Alternator | 90 amps |
| Battery | 12 V, CCA 950 |
| Starter | 12 V, 4 hp (3.0 kw) |
| Operator Station | Cab with ROPS |
Transmission
| Type | Hydrostatic transmission |
| Max Travel Speed (2-speed option) | 12 mph (19.2 km/h) |
| Tire Size | 12.00 x 16.5 HD |
Hydraulic System
| Standard Pump Flow | 23.6 gal/min (89 L/min) |
| High Flow Capacity | 34.9 gal/min (132 L/min) |
| Relief Valve Pressure | 3200 psi (22063 kPa) |
Service Refill Capacities
| Fuel Tank Capacity | 20 gal (75.7 L) |
| Engine Oil Capacity | 2.7 gal (10.4 L) |
| Cooling System Capacity | 1.7 gal (6.4 L) |
| Hydraulic Tank Capacity | 10.5 gal (39.8 L) |
