Dimensions
| Overall Length | 183.9 in (4670 mm) |
| Wheelbase | 141.7 in (3600 mm) |
| Overall Width | 84.4 in (2144 mm) |
| Maximum Working Width | 82 in (2084 m) |
| Lateral overhang, left/right | 1.7/1.7 in (44/44 mm) |
| Height to Top of ROPS | 118.1 in (3000 mm) |
| Height to Top of Cab | 117.9 in (2994 mm) |
| Height to Top of Steering Wheel | 86.2 in (2189 mm) |
| Ground Clearance | 7.9 in (200 mm) |
| Loading Hight, minimum | 86.2 in (2189 mm) |
| Turning Radius – Inside | 267.6 in (6798 mm) |
| Turning Radius – outside | 334.8 in (8504 mm) |
| Center of gravity | 43.1 in (1095 mm) |
Tires
| Number of Front Tires | 4 |
| Number of Rear Tires | 4 |
| Front Tire Size | 11.00-R20 |
| Front Width over Tires | 72.1 in (1830 mm) |
| Rear Tire Size | 11.00-R20 |
| Rear Width over Tires | 72.1 in (1830 mm) |
Engine Details
| Number Of Cylinders | 4 |
| Engine Make | DEUTZ |
| Engine Model | DEUTZ TCD 2012 L04 2V |
| Displacement | 247 cu in (4.038 L) |
| Bore | 4 in (101 mm) |
| Stroke | 5 in (126 mm) |
| Gross Power | 136 hp (100 kw) |
| Power Measured @ | 2300 rpm |
| Peak Torque | 383.5 lb ft (520 Nm) |
| Torque Measured @ | 1600 rpm |
| Fuel Consumption (100% engine output) | 7.5 gal (28.3 L/h) |
| Fuel Consumption (average) | 3.4 gal (12.7 L/h) |
| Aspiration | Turbocharged |
| Emission Standards | US EPA Tier 4 + EU Stage IIIA |
Operational Specs
| Operating Weight with ROPS | 21074 lb (9559 kg) |
| Front Axle Load | 10361 lb (4740 kg) |
| Rear Axle Load | 10713 lb (4819 kg) |
| Load per Tire (front) | 2590 lb (1185 kg) |
| Load per Tire (rear) | 2678 lb (1205 kg) |
| Operating Voltage | 12 V |
| Alternator | 95 amps |
| Battery | 12 V, 135 Ah |
| Starter | 12 V, 5.4 hp (4 kw) |
| Acoustic Pressure LP(A) in Cab | 84 dB(A) |
| Acoustic Power LW(A), Measured | 104 dB(A) |
| Output, 1 pass / 1.2 mph (2 km/h) | 3707 yd2/h (3100 m2/h) |
| Output, 1 pass / 3.1 mph (5 km/h) | 93289 yd2/h (7800 m2/h) |
| Output, 1 pass / 5.0 mph (8 km/h) | 14950 yd2/h (12500 m2/h) |
| Output, 3 pass / 3.1 mph (5 km/h) | 3110 yd2/h (2600 m2/h) |
Water Sprinkler
| Water Sprinkler Type | Pressure |
| Water Sprinkler Pump Type | Membrane pump |
| Actuation, Sprinkling | Interval / manual |
Drive
| Type | Hydraulic motor |
| Max Working Speed | 5.9 mph (9.5 km/h) |
| Max Travel Speed | 11.8 mph (19.0 km/h) |
| Gradeability | 25% |
| Steering | Two-point steering |
| Steering Lock | ±30° |
| Oscillation Angle | ±2° |
| Level Compensation (front) | ±2.55 in (±65 mm) |
Brake System
| Service Brake, Mode of Action | Hydrostatic |
| Service Brake, Actuation | Drive lever |
| Parking Brake, Mode of Action | Spring loaded disc brakes |
| Parking Brake, Actuation | Electric and/or automatic |
| Emergency Brake, Mode of Action | Hydro-mechanical brake |
| Emergency Brake, Actuation | Foot Brake Pedal / Emergency Stop Button |
Service Refill Capacities
| Fuel Tank Capacity | 62.1 gal (235 L) |
| Engine Oil Capacity | 3.0 gal (11.5 L) |
| Cooling System Capacity | 5.8 gal (22 L) |
| Water Spray Tank Capacity | 51.6 gal (195 L) |
| Hydraulic System Capacity | 21.1 gal (80 L) |
| Wheel Gear Capacity | 2x 2.1 gal (2x 8 L) |
| Hydraulic Brakes Capacity | 0.05 gal (0.2 L) |
| Level Compensation (front) Capacity | 0.26 gal (1 L) |
