Dimensions
| Overall Length (with S-blade and ripper) | 240 in (6096 mm) |
| Overall Width (with S-blade and ripper) | 147 in (3734 mm) |
| Overall Height | 100 in (2540 mm) |
| Ground Clearance | 19 in (483 mm) |
Undercarriage
| Track Gauge | 78 in (1981 mm) |
| Shoe Size (Standard) | 22 in (559 mm) |
| Number of Shoes Per Side | 40 |
| Number of Track Rollers Per Side | 7 |
| Number of Carrier Rollers Per Side | 2 |
Engine Details
| Number Of Cylinders | 8 |
| Engine Make | Detroit Diesel |
| Engine Model | Detroit Diesel 8V-71T |
| Displacement | 568 cu in (9.4 L) |
| Bore | 4.25 in (108 mm) |
| Stroke | 5.00 in (127 mm) |
| Gross Power | 275 hp (202 kw) |
| Power Measured @ | 2100 rpm |
| Injection System | Mechanical unit injector fuel system |
| Compression Ratio | 17.0:1 |
| Aspiration | Turbocharged |
Operational Specs
| Operating Weight | 77162 lb (35000 kg) |
| Operating Voltage | 24 V |
| Alternator | 50 amps |
Transmission
| Transmission Model | Allison CRT6031 |
| Transmission Type | 3-speed forward/reverse power shift transmission |
| Number Of Forward Gears | 3 |
| Number Of Reverse Gears | 3 |
| Max Travel Speed | 6.1 mph (9.8 km/h) |
Service Refill Capacities
| Fuel Tank Capacity | 125 gal (473 L) |
| Engine Oil Capacity | 10.1 gal (38 L) |
| Cooling System Capacity | 34.1 gal (129 L) |
| Final Drives Fluid Capacity | 13.3 gal (50 L) |
