Dimensions
| Overall Length | 443.4 in (11263 mm) |
| Overall Width | 135.2 in (3433 mm) |
| Overall Height | 148.4 in (3769 mm) |
| Wheelbase | 216.1 in (5488 mm) |
| Ground Clearance | 22.5 in (571 mm) |
| Dump Height | 286.9 in (7287 mm) |
| Dump Ground Clearance | 33.2 in (844 mm) |
Weights
| Volvo A40F | Empty | Loaded |
|---|---|---|
| Front Axle Load | 36376 lb (16500 kg) | 45195 lb (20500 kg) |
| Rear Axle Load | 31085 lb (14100 kg) | 108467 lb (49200 kg) |
| Operating Weight | 67461 lb (30600 kg) | 153442 lb (69600 kg) |
Dump System
| Rated Payload | 85980 lb (39000 kg) |
| Body Capacity, Heaped | 31.4 yd3 (24.0 m3) |
| Body Capacity, Struck | 24.07 yd3 (18.4 m3) |
| Dump Angle | 70° |
| Raise Time | 12 sec |
| Lower Time | 10 sec |
Engine Details
| Number of Cylinders | 6 |
| Engine Make | Volvo |
| Engine Model | Volvo D16F-A |
| Displacement | 982 cu in (16.1 L) |
| Bore | 5.7 in (144 mm) |
| Stroke | 6.5 in (165 mm) |
| Gross Power | 469 hp (350 kw) |
| Net Power | 465 hp (347 kw) |
| Power Measured @ | 1800 rpm |
| Peak Torque | 1862 lb ft (2525 Nm) |
| Torque Measured @ | 1050 rpm |
| Aspiration | Turbocharged |
Operational Specs
| Rated Load Capacity | 85980 lb (39000 kg) |
| Operating Weight (empty) | 67461 lb (30600 kg) |
| Operating Weight (loaded) | 153442 lb (69600 kg) |
| Operating Voltage | 24 V |
| Alternator | 80 amps |
| Battery | 2x 12 V, 225 Ah |
| Starter | 24 V, 12 hp (9 kw) |
| ROPS | ISO3471, SAE J1040 |
| FOPS | ISO3449, SAE J231 |
| Noise Level (interior) | 74 dB(A) |
| Noise Level (exterior) | 112 dB(A) |
| Tire Size (Standard) | 29.5R25 |
| Tire Size (Optional) | 875/65R29 |
| Steering System | Hydro-mechanical articulated steering, self compensating design. Two double-acting steering cylinders |
| Steering Angle | 3.4 steering wheel turns lock-to-lock, ±45° |
Transmission
| Transmission Type | Fully automatic Volvo PT 2519 PowerTronic planetary transmission |
| Number of Gears | 9F / 3R |
| Max Forward Speed | 35.4 mph (57 km/h) |
| Max Reverse Speed | 11.2 mph (18 km/h) |
| Torque Converter | Torque converter with built-in lock-up function |
| Dropbox | Volvo IL2 ATC |
| Traction Control | Automatic traction control system (ATC) |
| Type of Axles | Volvo ARB H40 |
| Service Brakes | Fully hydraulic, wet multiple disc brakes with enclosed, forced oil-cooled multiple discs on all wheels |
| Brake Circuits | Two independent circuits: one for front axle and one for bogie axles |
| Secondary Brake | Dual brake circuits with rechargeable accumulators |
| Parking Brake | Spring-applied disc brake on the propeller shaft |
| Retarder | Service brake retarder function and Volvo Engine Brake (VEB) |
Service Refill Capacities
| Fuel Tank Capacity | 126.8 gal (480 L) |
| Engine Oil Capacity (w/ filter) | 14.3 gal (54 L) |
| Cooling System Capacity | 19.8 gal (75 L) |
| Transmission Oil Capacity | 10.6 gal (40 L) |
| Dropbox Fluid Capacity | 2.4 gal (9 L) |
| Hydraulic Tank Capacity | 64.7 gal (245 L) |
| Brake Cooling System | 59.7 gal (226 L) |
| Front Axle Fluid Capacity | 6.9 gal (26 L) |
| Bogie Axle Fluid Capacity | 14.8 gal (56 L) |
